8/10* x Digital inputs
4 x Temperature inputs
11 x Analog inputs
2 x Trigger inputs
2 x Knock inputs
*2 inputs required when using 2nd CAN Bus
8 x Peak and Hold injection drives
8 x Ignition drivers
10 x Auxiliary outputs^
+5V Sensor power supply
+8V Sensor power supply
^unused fuel and ignition drives can be used as additional Aux outputs
2* x CAN bus
1x Serial (RS232) connection
1x USB tuning connection
Advanced features not found on the Storm:
8 Peak and Hold injection drives, user definable current, 10 amp peak, 3 amp hold max.
Fully programmable E-throttle control complete with capability of gear shift throttle blip and antilag.
Two independent CAN modules.
30 general purpose tables (up from 20)
All Motorsport features including full gear shift control, cruise control, traction control, antilag and launch control.
Advanced closed loop lambda strategy and dual bank lambda control.
What’s in the box?
Supplied with USB tuning cable and mounting bracket.
Requires “A” & “B” looms or “A” & “B” connector kits.
